📜 [Wiki] 32” rims - list of available rims + discussion

Unicycles and Equipment
1

Current list of rims in 32” - please add key sub facts to rims as you come across them - discussions stay in the thread

LightBicycle Anax32

  • Type: Hookless
  • Tubeless: Ready
  • Inner/Outer Width: 30mm/36mm
  • Depth: 28mm
  • ERD: 649mm (not including nipple head dimension)
  • Weight: Standard 380+/-15g,Heavy Duty420g+/-15g
  • Offset: 3mm (asymmetric)
  • Weight Limit: Standard 130kg(380g),Heavy Duty150kg(420g)
  • Spoke Hole Angle: +6°/-7°
  • Spoke Tension: ≤145kgf recommended
  • Max Tire Pressure: 40psi/ 2.76bar
  • Tire: 2.1" ~ 2.7" recommended

BTLOS Titan i30 / J

  • Profile/Offset: Symmetrical
  • Rim Weight: Premium: 530+/-15g Extralight: 480+/-15g
  • Material: Premium: Toray 25% T800 + 75% T700 Carbon Fiber - Extralight: Toray 50% T800 + 50% T700 Carbon Fiber
  • ERD: 647mm ( Does not include the nipple )
  • External Width: 36mm
  • Depth: 28mm
  • Rim Type: Clincher/Bead Hook (they do offer hookless variant)
  • Max Spoke Tension: 130kgf
  • Max Rider Weight: 120kg
  • Max Tire Pressure: 80psi
  • Hole Count: 16H to 36H
  • Weave: UD/3K/12K
  • Finish: Matte/Glossy
  • Tubeless Compatible: Yes
  • Application: Mountain Bike, All Mountain
  • Tire Size: 2.3 - 2.7"

Nextie Unicorn 32”

  • BSD (Bead Seated Diameter): 686mm
  • ERD (Effective Rim Diameter): 644mm
  • Drillings: 28. 32. 36
  • External Width: 38mm
  • Internal Width: 30mm
  • Rim Height: 30mm
  • Weight: 480g
  • Valve Hole Diameter: 6.5mm (Presta) | 8.5mm (Schrader)
  • Spoke Holes Diameter: 4.5mm
  • Spoke Holes Angle: Axial 6° | Radial 6°
  • Assembly Hole Diameter: 7.5mm
  • Drain Holes: Optional
  • Tubeless Compatible: Yes
  • Strength: 130J
  • Tire Size: 2.0" ~ 2.75"
  • Tire Pressure: 20 ~ 35psi
  • Spoke Tension: 100 ~ 130kgf

Velocity Blunt 35

  • External Width : 35.0 mm
  • Internal Width : 30.2 mm
  • Rim Height: 22.0 mm
  • Weight : 666.0 g
  • Tire Widths: 50.0 mm - 70.0 mm
  • ERD: 661.0 mm
  • BSD: 686.0 mm
  • Tire Type: Tubeless / Clincher
  • Brake Type: Disc Brake
  • Valve Type: Presta 32-40 mm
  • Material: 6061-T6
  • Drillings: 28, 32, 36, 40

Nimbus

4 Likes
New 32" tyres - is it what 32" unicycles need to become mainstream?
2
2 Likes
3

Does anyone have any experience with BTLOS? Ideally the 32" rim but I’m also curious about the company/manufacturing/quality in general. So if anyone has feedback on any of their rims I would appreciate it. I’m close to pulling the trigger on a 32.

4

I believe @muni_ben rides such a rim (link to his post). He may have great insights :slight_smile:

1 Like
5

I haven’t had any issues with my 2 BTLOS rims (28" and 32") so far. Weight and ERD were correct, tires fit well… trouble-free just like the rims from LB or Nextie.

2 Likes
6

Thanks Ben. Which BTLOS 32" rim do you have: Premium or Extralight?

7

Extralight
